SLOTTED CHEESE HEAD MACHINE SCREW DIN 84 4.8 CLASS - ZINC PLATED - T55-30601B DIN 84 - ACIER CLASSE 4.8 ZN DIN 84 (Model : T55-30601B)

Home » Tools » Maintenance, fixing and gluing » Fasteners and fixing systems » SLOTTED CHEESE HEAD MACHINE SCREW DIN 84 4.8 CLASS - ZINC PLATED - T55-30601B DIN 84 - ACIER CLASSE 4.8 ZN DIN 84 (Model : T55-30601B)

Photos

Dessins techniques

EXAMPLE OF ORDER :

Référence FI T55-30601B4X10

Information

Rondelle à denture extérieure chevauchante AZ - NFE 27625 - Acier ressort Zn 400 HBS - modèle T55-72001B

Files

• Maintenance, fixation et collage

Schéma 0

Quantity



CAD

Avail. --------- All NC D

Price * ----------- All NC

Ref ---- All T55-30601B-4X10 T55-30601B-4X16 T55-30601B-4X20 T55-30601B-4X30 T55-30601B-4X40 T55-30601B-5X10 T55-30601B-5X16 T55-30601B-5X20 T55-30601B-5X30 T55-30601B-5X40 T55-30601B-5X50 T55-30601B-6X16 T55-30601B-6X20 T55-30601B-6X30 T55-30601B-6X40 T55-30601B-6X50 T55-30601B-6X60

+

dxL (mm) ------------ All 4x10 4x16 4x20 4x30 4x40 5x10 5x16 5x20 5x30 5x40 5x50 6x16 6x20 6x30 6x40 6x50 6x60

d - All M4 M5 M6

dk (mm) ----------- All 7 8,5 10

k (mm) --------- All 2,6 3,3 3,9



NC

NC

T55-30601B-4X10

4x10

M4

7

2,6



D

NC

T55-30601B-4X16

4x16

M4

7

2,6



NC

NC

T55-30601B-4X20

4x20

M4

7

2,6



NC

NC

T55-30601B-4X30

4x30

M4

7

2,6



NC

NC

T55-30601B-4X40

4x40

M4

7

2,6



NC

NC

T55-30601B-5X10

5x10

M5

8,5

3,3



NC

NC

T55-30601B-5X16

5x16

M5

8,5

3,3



NC

NC

T55-30601B-5X20

5x20

M5

8,5

3,3



NC

NC

T55-30601B-5X30

5x30

M5

8,5

3,3



NC

NC

T55-30601B-5X40

5x40

M5

8,5

3,3



NC

NC

T55-30601B-5X50

5x50

M5

8,5

3,3



NC

NC

T55-30601B-6X16

6x16

M6

10

3,9



NC

NC

T55-30601B-6X20

6x20

M6

10

3,9



D

NC

T55-30601B-6X30

6x30

M6

10

3,9



NC

NC

T55-30601B-6X40

6x40

M6

10

3,9



D

NC

T55-30601B-6X50

6x50

M6

10

3,9



NC

NC

T55-30601B-6X60

6x60

M6

10

3,9
